On-grid Solar Inverter

Think Energy

NCE ECO ENERGY Solutions

With the team of highly specialized professionals NCE EcoEnergy Solution provides complete energy analysis and assessment service which helps customer to reduce POWER Consumption and save energy

Energy Assessment Methodology

• Preliminary Survey of Site, problem and gap identification.
• Gathering of data like monthly bills, utilization report from responsible authority.
• Detailed energy analysis.
• Report preparation and Recommendations.
• Recommendations for optimizing the illumination at different locations at site.
• Presentation on Energy Saving methods/practise for the Staff.

Energy Assessment Benefits

• Reduced expenditure on energy e.g saving on electricity bills
• Reduced maintenance cost
• Increased productivity where working conditions are improved.
• Reduction of CO2 and other emissions.
• Reduction of regional and national energy demand.
• Conservation of natural resources particularly fossil fuels and other non-renewable fuels.

Mounting Structures

• Available in material like aluminium/MS/Galvanized steel
• Professionaly designed and pre fabricated rooftop and ground mounting for optimised power generation.
• High Reliability with guranteed 0̃+4.99Wp power output, tolerance ensuring return on investment.
• Integrated Functions.
• Can withstand wind and snow loads. Excellent corrosion resistant.

NET METERING


1) Net metering is the concept which records net energy between export of generated energy and import of Discom energy for a billing month. Alternatively, the meter, having the feature of recording both the import and export values, besides other parameters notified by CEA metering regulations and APTRANSCO / Discom procedures in vogue, shall also be allowed for arriving net energy for the billing period.

2) For implementing the above, the government of Tamil Nadu has announced a policy on Net Metering for solar grid interactive rooftop and small SPV Power plants in the state vide G.O.Ms.No.00, dated 00.00.0000.

Solar PV Power Generation:

1) Sunlight is converted to electricity directly when made to fall on solar photovoltaic (SPV) modules. Systems/devices are made for various applications based on SPV modules connected with suitably designed power conditioning units for meeting electricity requirements.

2) Grid connected roof top solar PV system: In recent years solar PV systems became viable and attractive. Utility scale plants are being set up worldwide with promotional mechanisms which are set up on ground surface. Available roof-top area on the buildings can also be used for setting up solar PV power plants, and thus dispensing with the requirement of free land area. The electricity generated from SPV systems can also be fed to the distribution or transmission grid after conditioning to suit grid integration. .

On-grid Inverter With Energy Storage:

• 1.5KW/2KW/3KW/5KW on-grid PV inverter
• Advanced DSP control technology delivers accurate data
• Two smart independent MPPTs to enhance overall efficiency
• Up to 96% high conversion efficiency
• Modulated design for easy maintenance
• Industrial-grade components used for robust operation
• Data log up to 15 years
• IP 65 protection for outdoor and harsh environment
• 5-year product warranty
• Net Metering is available
• Optional monitoring software

On-grid Inverter Selection Guide:


MODEL EnerSolar 1.5KW EnerSolar 2KW EnerSolar 3KW EnerSolar 5KW
INPUT(DC)
Max. DC Power 1650 W 2200 W 3300 W 5000 W
Maximum DC Voltage 450 VDC 500 VDC 500 VDC
MPP Voltage Range 150 VDC ~ 400 VDC 200 VDC ~ 450 VDC 250 VAC ~ 500 VDC 180 VDC ~ 500 VDC
Nominal DC Voltage 360 VDC 370 VDC
Start-up Voltage / Initial Feeding Voltage 120VDC / 150VDC 125VDC / 150VDC
Maximum Input Current 1 x 11A 1 x 13A 2 x 15A
Number of MPP Trackers / Strings per MPP Tracker 1 / A:1 1 / A:1 2 / A:1;B:1
OUTPUT(AC)
AC Nominal Power 1500 W 2000 W 3000 W 4600 W
Maximum AC Apparent Power 1600 VA 2100 VA 3000 VA 4600 VA
Nominal AC Voltage 230 VAC
AC Voltage Range 184-264 VAC*
AC Grid Frequency 50 Hz / 60 Hz
Nominal Output Current 6.6 A 8.7A 13 A 20 A
Power Factor @ Rated Power > 0.99
EFFICIENCY
Maximum Efficiency 96% 97.3% 97.3%
European Efficiency @ Nominal Voltage & 100% Load 95% 96.4% 96.7%
PROTECTION
DC Reverse-Polarity Protection Yes
Ground Fault Monitoring Yes
Grid Monitoring Yes
AC Short Circuit Protection Yes
Over Current Protection 30 A 30 A 30 A 50 A
Over Current Protection 30 A 30 A 30 A 50 A
PHYSICAL
Dimension,DxWxH(mm) 136.5 x 268.5 x 410 182 x 308 x 515
Net Weight (kgs) 11.5 11.5 15.0 20.0
INTERFACE
Intelligent Slot USB & RS-232 card / Option: SNMP card and Modbus card
ENVIRONMENT
Humidity 0 ~ 100% RH (No condensing)
Operating Temperature -25°C to 60°C
Altitude 0 ~ 1000 m**
COMPLIANCE
Standard CE, VDE-AR-N 4105, IEC62109, ENEL Guide 2009, RD 1663, G83/1-1, AS3100/AS4777

*The AC Voltage Range may vary depending on different country grid standard
**Power derating 1% every 100 m when altitude is over 1000m.
Product specifications are subject to change without further notice.


10KW Three Phase On-grid Inverter

• 1.5KW/2KW/3KW/5KW on-grid PV inverter
• Advanced DSP control technology delivers accurate data
• Two smart independent MPPTs to enhance overall efficiency
• Up to 96% high conversion efficiency
• Modulated design for easy maintenance
• Industrial-grade components used for robust operation
• Data log up to 15 years
• IP 65 protection for outdoor and harsh environment
• 5-year product warranty
• Net Metering is available
• Optional monitoring software

On-grid 10KW Inverter Selection Guide:


MODEL EnerSolar 10KW
INPUT(DC)
Max. DC Power 11000 W
Maximum DC Voltage 900 VDC
MPP Voltage Range 320 VDC ~ 800 VDC
Nominal DC Voltage 600 VDC
Start-up Voltage / Initial Feeding Voltage 250VDC / 250VDC
Maximum Input Current 2 x 17A / 17 A
Number of MPP Trackers / Strings per MPP Tracker 2 / A:1;B:1
OUTPUT(AC)
AC Nominal Power 10000 W
Nominal AC Voltage 3/N/PE, 230VAC/400VAC
AC Voltage Range -20% ~ +15%*
AC Grid Frequency 50 Hz
AC Grid Frequency Range 47.5~ 50.2 Hz
Nominal Output Current 14.5A
Power Factor @ Rated Power > 0.99
EFFICIENCY
Maximum Efficiency 98%
European Efficiency @ Nominal Voltage & 100% Load 97%
PROTECTION
DC Reverse-Polarity Protection Yes
Ground Fault Monitoring Yes
Grid Monitoring Yes
AC Short Circuit Protection Yes
Over Current Protection 30 A / Phase
PHYSICAL
Dimension,DxWxH(mm) 171.2 x 503.5 x 653.3
Net Weight (kgs) 40
INTERFACE
Intelligent Slot USB & RS-232 card / Option: SNMP card and Modbus card
ENVIRONMENT
Humidity 0 ~ 100% RH (No condensing)
Operating Temperature -25°C to 60°C
Altitude 0 ~ 1000 m**
COMPLIANCE
Standard CE, VDE-AR-N 4105, IEC62109, ENEL Guide 2009, RD 1663, G83/1-1, AS3100/AS4777

*The AC Voltage Range may vary depending on different country grid standard
** Power derating 1% every 100 m when altitude is over 1000m.
Product specifications are subject to change without further notice.
